Chain faceting tools

Introduction:

Diamond chain faceting tools are used for  mirror bright cutting on gold, silver, platinum chains. We use top quality nature and mono crystal diamond material. Beside side cutting tools with several angles for left and right cutting, we also offer the mini tools, tools with long body and different tools depending on different machine manufacturers, for ice lathe. even special design tools with high precision values are always welcome as orders.

Specification:

•Shank size: 18 x 8 x 6 mm

•Center hole: 4 mm

•Diamond size available: 0.50 mm - 10.00 mm

•Can be made as per customers provided prints or specifications

Chain faceting tool(left&right) and mini chain tool selectable

Advantage:

•Natural diamond and mono tools for chain faceting

•Compatible with world-wide chain faceting machines - Ompar, Faimond, Sisma and others

•Wide range of products for different machinery

•Special orders welcome for customised machines



—

Chain Faceting Tools

We make Chain cutting tools which are widely used for mirror bright cutting on gold,silver platinum chain.Beside side cutting tools with sereral angles for left and right cutting, we also offer mini chain tools and disc tools.

Chain Faceting Tools With Left&Right  Side Cutting

Product: Chain Faceting tools

Model no: 300103

Optional Material: Nature diamond, MCD, CVD, PCD, Carbide.

Diamond Size: 0.25mm-8mm

Shank Material: Stainless Steel

Tool Angle: 15°,22.5°,30°,45°,67.5°,75°

Application: Chain Faceting Machine

All tools can be customized according to customers’ requirements

Mini Chain Tools for

Chain Facting

Product: Mini Chain tools

Model no: 300102

Optional Material: Nature diamond, MCD, CVD, PCD, Carbide.

Diamond Size: 0.25mm-8mm

Shank Material: Stainless Steel

Application: Chain Machine

All tools can be customized according to customers’ requirements

     Disc Tool

Product: Disc Tool

Model no: 600101

Optional Material: Nature diamond, MCD, CVD, PCD.

Disk Profile: 90° to 180° .

Disk Material: Stainless Steel

Application: Semi-Automatic machine or CNC Machine

All tools can be customized according to customers’ requirements

Chain Faceting Tools:

Disc Tool Texture Samples
